1 Pair 20m Infrared Photoelectric Beam Alarm, Security Light Barrier Sensor Detector for Home Door Window Outdoor Security

Product description

ZAWELIYO 1 Pair 20m Infrared Photoelectric Beam Alarm, Security Light Barrier Sensor Detector for Home Door Window Outdoor Security

Housed in hard plastic shells, these detectors operate effectively in temperatures from -10℃ to 70℃, ensuring year-round reliability for your property security needs.

Suitable for both home security systems and commercial use, this infrared sensor detector provides reliable protection for schools, offices, parking areas, and residential properties with its 1A relay output for alarm connectivity.

Designed with 940nm wavelength technology and advanced circuitry, this photoelectric detector maintains stable in various conditions, though range may reduce by 30% during heavy fog, rain, or dust.

1. Made of plastic shell, eco‑friendly, and sturdy to use

2. Create a reliable and invisible infrared beam up to 20 meters

3. Infra‑red frequency: 1.92Khz; Power supply: DC 12V; Wave length: 940nm

4. Half egg shaped, input: >50mA, operating temperature: ‑10℃ to 70℃

5. Range can be reduced to 30% in bad weather conditions: fog, rain, dust, etc

Spec:

Description:

This pair of infrared detector need install them at the opposite positions. There is a infrared area between these two detector parts. When someone passes the infrared region for an adjusted response time, the detector will send alarm signal, great for security system in school, office building, hospital, parking and home yard, etc.

Features:

Made of plastic shell, , and sturdy to use.

Create a reliable and invisible infrared beam up to 20 meters.

Infra-red frequency: 1.92Khz; Power supply: DC 12V; Wave length: 940nm.

Half egg shaped, input: RX 15mA-TX 30mA, operating temperature: -10℃ to 70℃

Range can be reduced to 30% in bad weather conditions: fog, rain, dust, etc.

Specification:

Condition: 100% New Brand

Shell Material: Plastic

Receiver Range : Less than 20m

Infra-red Frequency: 1.92KHZ

Wavelength: 940nm

Voltage: DC 12V

Input: RX 15mA-TX 30mA

Operating Temperature: -10℃ to 70℃

Relay Output: 1A maximum 30V, constant open/close, can be set by jumper wire

Size (L x W x T): Approx. 76 X 49.2 X 21.6mm / 3 x 1.9 x 0.9inch

Package Weight: Approx. 130g

Package Included:

1 x Transmitter

1 x Receiver

1 x Set of Accessories

1 x User Manual

Note:

1. The best installation height should be more than 20 cm, distance is not less than 2 meters.

2. Infrared protection device should be installed vertically, and at the same level.

3. First installing receiver, then installing transmitter. When the off light of receiver is turning off, then fixed it, installation finished.

4. Distance between receiver and transmitter need be more than 1m, otherwise it will be insensitive.

5. Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.

20 Meter Infrared Beam Protection: This infrared photoelectric beam creates an invisible security barrier spanning up to 20 meters between transmitter and receiver, triggering an immediate alarm when the beam is interrupted by intruders.
Designed with 940nm wavelength technology and advanced circuitry, this photoelectric detector maintains stable operation in various conditions, though range may reduce by 30% during heavy fog, rain, or dust.
The complete photoelectric beam alarm system includes one transmitter and one receiver that install on opposite sides of doorways, window, or pathways, creating an effective security perimeter with DC 12V power requirement.
Suitable for both home security systems and commercial use, this infrared sensor detector provides reliable protection for schools, offices, parking areas, and residential properties with its 1A relay output for alarm connectivity.
Housed in hard plastic shells, these detectors operate effectively in temperatures from -10℃ to 70℃, ensuring year-round reliability for your property security needs.
